tvONE

MX-8488

8x8 HDMI / HD-BaseT Routing Switcher

Mehr Ansichten

tvONE
MX-8488
8x8 HDMI / HD-BaseT Routing Switcher
Bitte loggen Sie sich ein um Ihren Preis zu sehen
Beschreibung

Details

TheMX-8488 is designed to distribute up to 8 HDMI sources (with 3D support) to up to 8 different destinations via HDBaseT over Cat.6. The MX-8488 supports HDMI (with HDCP) video with Deep Color, EDID and 7.1 channel audio. The video quality is excellent and the switcher uses single link (225MHz/6.75Gbps) video processing circuitry. The MX-8488 HDMI Matrix Switcher offers a convenient and cost effective method for the switching of high quality HDMI video. The MX-8488 is ready to provide an HDMI matrix switching solution ideal for boardroom, showroom, or exhibition use. Regardless of whether you use the IR remote, RS-232, Ethernet, or the front panel push button operation, control of the MX-8488 couldn't be easier. The MX-8488 is compatible with the following tvONE HDBaseT receivers: HD One LX/DX (non-POH mode only), 1T-CT-652, 1T-CT-654 and 1T-CT-642.

Zusatzinformation

Zusatzinformation

Allgemein

Artikelnummer 8624-0287-01
Hersteller tvONE
Lieferzeit 2-14 Tage

Eigenschaften

Eigenschaften
  • HDMI v1.3, HDCP v1.1 & DVI v1.0 compliant
  • Deep Color & 3D support
  • 7.1 LPCM, Dolby TrueHD & DTS-HD Master Audio support
  • IR I/O support
  • Rack-mountable
  • Controllable via Front panel, RS-232, IR & Ethernet
  • EDID setting support
  • PC resolutions VGA-WUXGA
  • Video resolutions 480i-1080p
  • Power over HDBaseT support
HDbaseT 5-Play
HDCP compliant Ja
3D fähig Ja
Steuerung Bedienfeld, RS-232, IP, IR

Inputs

HDMI IN 8x
Audio IN embedded Audio

Outputs

Audio OUT embedded Audio
CATx OUT 8x
